Cryogenic liquid CO2 storage tank is double walled, with 16MnDR as the internal material and Q245R carbon steel as the external material. cryogenic liquid CO2 storage tank has two structures: vertical and horizontal. It adopts vacuum powder insulation. It has the advantages of compact structure, short release date, small floor area, centralized control, safety and reliability, convenient operation and maintenance, etc.
InquiryCryogenic liquid CO2 storage tank has the advantages of compact structure, low daily evaporation rate, small footprint, centralized control, safety and reliability, and convenient operation and maintenance.
| Model | Effective volume (M3) |
Working pressure (Bar) |
Dimension (mm) |
Weight (Kg) |
| CFL-5/2.16 | 5 | 21.6 | Φ2000*5130 | 4450 |
| CFL-10/2.16 | 10 | Φ2100*7170 | 6986 | |
| CFL-15/2.16 | 15 | Φ2100*6912 | 8810 | |
| CFL-20/2.16 | 20 | Φ2500*8756 | 11328 | |
| CFL-25/2.16 | 25 | Φ2900*7728 | 14660 | |
| CFL-30/2.16 | 30 | Φ2900*8875 | 17961 | |
| CFL-50/2.16 | 50 | Φ3200*11320 | 26097 | |
| CFL-60/2.16 | 60 | Φ3200*13180 | 30220 | |
| CFL-100/2.16 | 100 | Φ3500*16870 | 49627 |
Application: This series of cryogenic liquid CO2 storage tanks metallurgy, chemical industry, food, fire fighting and many other industries. The product has the advantages of compact structure, safety and reliability, convenient operation and maintenance, etc.
After-Sales Service: We provide after-sales service for one year. We also have branches in Vietnam, which can provide door-to-door installation and after-sales service for local and surrounding countries.
