Cryogenic liquid storage tank is double-walled, with s30408 stainless steel as the internal material and Q245R carbon steel as the external material. Cryogenic liquid storage tank has two structures: vertical and horizontal. It adopts vacuum powder insulation. It has the advantages of compact structure, short release date, small floor area, centralized control, safety and reliability, convenient operation and maintenance, etc.
InquiryCryogenic liquid storage tank has the advantages of compact structure, low daily evaporation rate, small footprint, centralized control, safety and reliability, and convenient operation and maintenance.
| Model | Effective volume (M3) |
Working pressure (Bar) |
Dimension (mm) |
Weight (Kg) |
| CFL-5/0.8 | 5 | 8 | Φ2000*5130 | 3412 |
| CFL-10/0.8 | 10 | Φ2100*7170 | 5378 | |
| CFL-15/0.8 | 15 | Φ2100*6912 | 6415 | |
| CFL-20/0.8 | 20 | Φ2500*8756 | 8255 | |
| CFL-30/0.8 | 30 | Φ2900*8870 | 12899 | |
| CFL-50/0.8 | 50 | Φ3100*12058 | 18960 | |
| CFL-5/1.6 | 5 | 16 | Φ2000*5130 | 3945 |
| CFL-10/1.6 | 10 | Φ2000*7895 | 6787 | |
| CFL-15/1.6 | 15 | Φ2400*7552 | 8628 | |
| CFL-20/1.6 | 20 | Φ2400*9371 | 10744 | |
| CFL-30/1.6 | 30 | Φ2700*10310 | 14640 | |
| CFL-50/1.6 | 50 | Φ3100*12058 | 23370 |
Application: This series of cryogenic liquid storage tanks are widely used in manufacturing plant, food & Beverage Factory, construction works, energy & Mining and many other industries.
After-Sales Service: We provide after-sales service for one year. We also have branches in Vietnam, which can provide door-to-door installation and after-sales service for local and surrounding countries.
