The new generation of the reciprocating cryogenic liquid filling pump is elaborately designed and produced by our company, based on the latest technologies introduced from foreign countries. Cryogenic liquid filling pump is compatible with liquid oxygen, liquid nitrogen, and liquid argon fill-up systems. The function of this pump is filling the liquid gas to the steel cylinder from gas tank. The stability of the equipment in long-running is guaranteed by the simplified and optimized design and elaborate manufacture.
InquiryCryogenic liquid filling pump has the advantages of stable performance, convenient operation and maintenance, short start-up time and stable operation. The pump head adopts high-vacuum multi-layer thermal insulation, which reduces the cold loss of the working medium. Activates when depressurized.
| Model | Type | Working medium | Flow Range | Inlet pressure(Mpa) | Max Pressure(Mpa) |
| BP50-150/165 |
Single Horizontal Piston
|
liquid oxygen liquid nitrogen liquid argon |
50-150 |
0.02-0.8 |
16.5 |
| BP100-450/165 | 100-450 | ||||
| BP300-600/165 | 300-600 | ||||
| BP400-800/165 | 400-800 | ||||
| BP800-1600/165 | 800-1600 | ||||
| BP100-450/200 | 100-450 | 0.02-0.8 | 20.0
|
||
| BP300-600/200 | 300-600 | ||||
| BP200-450/250 | 200-450 | 25.0 | |||
| BP300-600/250 | 300-600 | ||||
| BP300-600/350 | 300-600 | 35.0 |
Application: This series of cryogenic liquid filling pump is widely used in Industrial Utilities, Machining, Mining industry, Cryogenic liquid oxygen, nitrogen, argon.
After-Sales Service: We provide after-sales service for one year. We also have branches in Vietnam, which can provide door-to-door installation and after-sales service for local and surrounding countries.
